Evolution 4-9 Rear Diffential Rebuild Services

Click Here to Request a Quote for your EVO 4-9

_MG_5003-Edit

The basic rear diff rebuild service is $525.

Includes the following services and parts:

  • The rear diff is disassembled and hot tanked to remove all dirt, grease and oil.
  • Parts are then glass beaded and then inspected for wear and components are magnafluxed checked for cracks.
  • Cast iron housing is glass beaded and epoxy painted.
  • Pinion flange glass beaded, painted and then turned true to rule out any vibration from a damaged pinion flange.
  • New Upper and Lower Pinion Gear Tapered Roller Bearings
  • New Carrier Housing Right and Left Tapered Roller Bearings
  • New Shims for Bearing Preload Setup, Pinion Height / Gear Backlash Setup, and Proper Gear Contact Pattern
  • New Pinion Flange Seal
  • New Rear Axle Seals
  • New Fasteners
  • New Fill Plug and Washer
  • New Magnetic Drain Plug and Washer

Additional Upgrades & Parts:

  • JDM EVO Mechanical Type Rear Differential $300.
  • TRE Heavy Duty Rear Diff Basket. $425
  • TRE Heavy Duty Side Cover. $235.
  • TRE 12 plate MAX-LOCK Friction Discs. $325.
  • TRE Oil Sight Rear Cover. $115.
  • CNC machining of the Cross Shaft and Side Sheaves. $85.
  • TRE Heavy Duty Rear Diff Basket. $425.

The full TRE race prepped rear diff rebuild service is $1250.

Includes the following services and parts:

  • The rear diff is disassembled and hot tanked to remove all dirt, grease and oil.
  • Parts are then glass beaded and then inspected for wear and components are magnafluxed checked for cracks.
  • Cast iron housing is glass beaded and epoxy painted.
  • Pinion flange glass beaded, painted and then turned true to rule out any vibration from a damaged pinion flange.
  • New Upper and Lower Pinion Gear Tapered Roller Bearings
  • New Carrier Housing Right and Left Tapered Roller Bearings
  • New Shims for Bearing Preload Setup, Pinion Height / Gear Backlash Setup, and Proper Gear Contact Pattern
  • New Pinion Flange Seal
  • New Rear Axle Seals
  • New Fasteners
  • New Fill Plug and Washer
  • New Magnetic Drain Plug and Washer
  • TRE Heavy Duty Side Cover. 3x the rigidity over the OEM side cover. Eliminates deflection of the ring gear during hard clutch dumps. Large crush-proof bearing post design.
  • TRE 12 plate MAX-LOCK friction disc upgrade, these are most aggressive and durable friction discs available.
  • TRE Oil Sight Rear Cover.  Allows visual indication of oil quality while increasing oil capacity by 50%.
  • CNC machining of the Cross Shaft and Side Sheaves to eliminate most of the “clunk” from the rear diff.
  • CNC machining of the Rear Diff Basket to increase the radius of the housing. Improves the strength against cracking.
  • Gear Detail & Tooth Profile Modification of the Ring & Pinion gearset. Proven to increase the durability of the gear teeth.
  • Shot Peening of the Ring & Pinion, Spider Gearset, Cross Shaft, Side Sheaves, Rear Diff Basket. We make them stronger.

Additional Upgrades & Parts:

  • JDM EVO Mechanical Type Rear Differential $300.
  • TRE Heavy Duty Rear Diff Basket. $425
  • TRE Heavy Duty Side Cover. $235.
  • TRE 12 plate MAX-LOCK Friction Discs. $325.
  • TRE Oil Sight Rear Cover. $115.
  • CNC machining of the Cross Shaft and Side Sheaves. $85.
  • TRE Heavy Duty Rear Diff Basket. $425.

Turn-around times for the rear diff service is about a week.

Inbound Shipping and Insurance, in the lower 48 States, ranges from $45 – 75.

Outbound Shipping and Insurance, in the lower 48 States, ranges from $45 – $75.

If you don’t have a core to send in for this service, the core charge is $900.
